YG-1 Square End Mill: 1" Dia, 1-1/8" LOC, 6" OAL, 3" Reach, 4 Flute, Y-Coating, UGMF73911

YG-1

No reviews yet Write a Review
SKU:
YG1-UGMF73911
$947.16

YG-1 square end mill for steel, stainless steel and cast iron, 4 flutes, Weldon flat shank. Y-Coating. Manufacturer part number UGMF73911.

Specifications

Unit of Measure
Inch
Cutting Diameter (Fractional)
1
Length of Cut (Fractional)
1-1/8
Shank Diameter (Fractional)
1
Number of Flutes
4
Shank Type
Weldon Flat
Overall Length (Fractional)
6
Size System
Fractional
Coating/Finish
Y-Coating
Length of Cut (Decimal)
1.1250
Length of Cut (Metric)
28.58
Shank Diameter (Decimal)
1.0000
Shank Diameter (Metric)
25.40
Overall Length (Decimal)
6.0000
Overall Length (Metric)
152.40
Reach (Fractional)
3
Cutting Diameter (Decimal)
1.0000
Cutting Diameter (Metric)
25.40
Reach (Metric)
76.20
Reach (Decimal)
3.0000
Secondary Workpiece Material
High-Temp Alloy
Workpiece Material
Steel, Stainless Steel, Cast Iron
$947.16
