20.0 x 20 x 92 2FL SHORT BALL X-POWER

YG-1

No reviews yet Write a Review
SKU:
YG1-EM876200
$486.41

Specifications

Series
EM876
Unit of Measure
Metric
Diameter
20 mm
Length of Cut
20 mm
Shank Size
20 mm
Shank Type
Plain
Overall Length
92 mm
Cutting Direction
Right
Material
Carbide
Coating/Finish
AlTiN
Length of Cut (Decimal)
0.79
Length of Cut (Fractional)
37/47
Shank Diameter (Decimal)
0.79
Shank Diameter (Fractional)
37/47
Overall Length (Decimal)
3.62
Overall Length (Fractional)
3-28/45
Number of Flutes
2
Diameter (Decimal)
0.79
Workpiece Material
Steel
Diameter (Fractional)
37/47
Ball Nose Radius (Decimal)
0.39
Ball Nose Radius (Metric)
10
Ball Nose Radius (Fractional)
37/94
Cut Type
Center Cut
$486.41
