25 x 25 x 38 x 104 V7 MILL INOX 4FL LONG BALL CARBIDE FLAT SHANK

YG-1

No reviews yet Write a Review
SKU:
YG1-EMB75250
$717.48

Specifications

Series
EMB75
Unit of Measure
Metric
Diameter
25 mm
Length of Cut
38 mm
Shank Size
25 mm
Shank Type
Flat
Overall Length
104 mm
Cutting Direction
Right
Material
Carbide
Coating/Finish
AlTiN
Length of Cut (Decimal)
1.50
Length of Cut (Fractional)
1-1/2
Shank Diameter (Decimal)
0.98
Shank Diameter (Fractional)
62/63
Overall Length (Decimal)
4.09
Overall Length (Fractional)
4-5/53
Helix Angle
Variable
Number of Flutes
4
Diameter (Decimal)
0.98
Workpiece Material
"Steel, Stainless Steel, High-Temp Alloy"
Diameter (Fractional)
62/63
Ball Nose Radius (Decimal)
0.49
Ball Nose Radius (Metric)
12.50
Ball Nose Radius (Fractional)
31/63
Cut Type
Center Cut
$717.48
