YG-1 Spiral Point Tap: M8 x 1, D5, Plug, 2 Flute, Steam Oxide, HSS, T6217375

YG-1

No reviews yet Write a Review
SKU:
YG1-T6217375
$18.70

YG-1 spiral point tap for steel, 2 flutes, plug chamfer, square shank. HSS, steam oxide finish. Manufacturer part number T6217375.

Specifications

Unit of Measure
Metric
Workpiece Material
Steel
Number of Flutes
2
Shank Type
Square
Overall Length (Decimal)
2.7200
Material
HSS
Coating/Finish
Steam Oxide
Shank Diameter (Decimal)
0.3180
Shank Diameter (Metric)
8.08
Overall Length (Metric)
69.09
Performance Class
General Purpose
Thread Standard
MF
Thread Size
M8 x 1
LxD Ratio
3xD
Thread Limit
D5
Chamfer
Plug
Thread Pitch (mm)
1
Blank Standard
302
Chamfer Length
4P-5P
Secondary Workpiece Material
Stainless Steel, Cast Iron, Non-Ferrous
Drill Size (Decimal)
0.2792
Drill Size (Metric)
7.09
Square Length (Decimal)
0.3800
Square Length (Metric)
9.65
Square Size (Decimal)
0.2380
Square Size (Metric)
6.05
Thread Length (Decimal)
1.1260
Thread Length (Metric)
28.60
