YG-1 Spiral Point Tap: 3/8-16, H5, Plug, 3 Flute, TiCN, M6485

YG-1

No reviews yet Write a Review
SKU:
YG1-M6485
$56.30

YG-1 spiral point tap for steel, 3 flutes, plug chamfer, square shank. TiCN coating. Manufacturer part number M6485.

Specifications

Unit of Measure
Inch
Number of Flutes
3
Shank Type
Square
Overall Length (Decimal)
2.9370
Coating/Finish
TiCN
Shank Diameter (Decimal)
0.3810
Shank Diameter (Metric)
9.68
Overall Length (Metric)
74.60
Workpiece Material
Steel
Thread Standard
UNC
Thread Size
3/8-16
LxD Ratio
3xD
Thread Limit
H5
Chamfer
Plug
Thread Pitch (TPI)
16
Blank Standard
302A
Chamfer Length
4P-5P
Secondary Workpiece Material
Hardened Steel
Drill Size (Decimal)
0.3182
Drill Size (Metric)
8.08
Square Length (Decimal)
0.4400
Square Length (Metric)
11.18
Square Size (Decimal)
0.2860
Square Size (Metric)
7.26
Thread Length (Decimal)
0.7480
Thread Length (Metric)
19.00
Usable Length (Decimal)
1.2520
Usable Length (Metric)
31.80
YG-1 Spiral Point Tap: 3/8-16, H5, Plug, 3 Flute, TiCN, M6485
$56.30
