YG-1 Square End Mill: 5/8" Dia, 1-1/4" LOC, 3-1/2" OAL, 2 Flute, Bright/Uncoated, 01595

YG-1

No reviews yet Write a Review
SKU:
YG1-01595
$162.32

YG-1 square end mill for steel, 2 flutes, 30 degree helix, straight shank. Bright/uncoated. Manufacturer part number 01595.

Specifications

Unit of Measure
Inch
Cutting Diameter (Fractional)
5/8
Length of Cut (Fractional)
1-1/4
Shank Diameter (Fractional)
5/8
Number of Flutes
2
Shank Type
Straight
Overall Length (Fractional)
3-1/2
Size System
Fractional
Coating/Finish
Bright/Uncoated
Length of Cut (Decimal)
1.2500
Length of Cut (Metric)
31.75
Shank Diameter (Decimal)
0.6250
Shank Diameter (Metric)
15.88
Overall Length (Decimal)
3.5000
Overall Length (Metric)
88.90
Helix Angle
30 degrees
Cutting Diameter (Decimal)
0.6250
Cutting Diameter (Metric)
15.88
Secondary Workpiece Material
Stainless Steel, Cast Iron, Non-Ferrous
Workpiece Material
Steel
$162.32
