Fullerton Square End Mill: 5/8" Dia, 1-5/8" LOC, 3-1/2" OAL, 5 Flute, TiAlN, 38168

Fullerton

No reviews yet Write a Review
SKU:
FUL-38168
$196.85

5/8" Dia, 1-5/8" LOC, 3-1/2" OAL Fullerton Square End Mill, manufacturer part number 38168.

Specifications: Cutting Diameter: 5/8 in (0.6250 in, 15.88 mm); Length of Cut: 1-5/8 in (1.6250 in, 41.28 mm); Overall Length: 3-1/2 in (3.5000 in, 88.90 mm); Shank Diameter: 5/8 in (0.6250 in, 15.88 mm); Number of Flutes: 5; Helix Angle: 45 degrees; Double Ended: No; Color: Violet-Gray; Length Type: Standard; Coolant Option: External Coolant; End Type: Square; Hand Direction: Right; Helix Direction: Right.

Coating/Finish: TiAlN. Unit of measure: Inch.

Specifications

Unit of Measure
Inch
Length of Cut (Decimal)
1.6250
Overall Length (Decimal)
3.5000
Double Ended
No
Hand Direction
Right
Coating/Finish
TiAlN
Cutting Diameter (Metric)
15.88
Length of Cut (Metric)
41.28
Length of Cut (Fractional)
1-5/8
Shank Diameter (Metric)
15.88
Shank Diameter (Fractional)
5/8
Overall Length (Metric)
88.90
Overall Length (Fractional)
3-1/2
Helix Angle
45 degrees
Cutting Diameter (Decimal)
0.6250
Number of Flutes
5
Cutting Diameter (Fractional)
5/8
Shank Diameter (Decimal)
0.6250
Length Type
Standard
Color
Violet-Gray
Coolant Option
External Coolant
End Type
Square
Helix Direction
Right
Size System
Fractional
Fullerton Square End Mill: 5/8" Dia, 1-5/8" LOC, 3-1/2" OAL, 5 Flute, TiAlN, 38168
$196.85
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
