Harvey Tool Ball End Mill: .187" Dia, 9/32" LOC, 4" OAL, 2" Reach, 2 Flute, Amorphous Diamond, 18912-C4

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-18912-C4
$206.70

Harvey Tool ball end mill, 2 flutes, center cutting. Solid carbide, Amorphous Diamond coating. Manufacturer part number 18912-C4.

Specifications

Unit of Measure
Inch
Cutting Diameter (Decimal)
0.1870
Length of Cut (Decimal)
0.2810
Shank Diameter (Decimal)
0.3750
Overall Length (Decimal)
4.0000
Coating/Finish
Amorphous Diamond
Length of Cut (Fractional)
9/32
Neck Diameter (Decimal)
0.2670
Number of Flutes
2
Neck Length (Decimal)
0.1870
Neck Length (Fractional)
3/16
Shank Diameter (Fractional)
3/8
Overall Length (Fractional)
4
Size System
Decimal
Center Cutting
Yes
Minor Diameter (Decimal)
0.1770
Minor Diameter (Metric)
4.50
Neck Angle
2
Tapered Reach (Decimal)
1.7500
Tapered Reach (Fractional)
1-3/4
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0010
End Type
Ball
LxD Ratio
1.5xD
Material
Solid Carbide
Reach (Decimal)
2.0000
Reach (Fractional)
2
Shank Tolerance
h6
Harvey Tool Ball End Mill: .187" Dia, 9/32" LOC, 4" OAL, 2" Reach, 2 Flute, Amorphous Diamond, 18912-C4
$206.70
