Harvey Tool Ball End Mill: 3/32" Dia, .074" LOC, 2-1/2" OAL, .972" Reach, 2 Flute, AlTiN Nano, 38993-C6

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-38993-C6
$106.20

Harvey Tool ball end mill for steel and stainless steel, 2 flutes, 35 degree helix. Solid carbide, AlTiN Nano coating. Manufacturer part number 38993-C6.

Specifications

Unit of Measure
Inch
Cutting Diameter (Decimal)
0.0930
Length of Cut (Decimal)
0.0740
Shank Diameter (Decimal)
0.2500
Overall Length (Decimal)
2.5000
Coating/Finish
AlTiN Nano
Overall Length (Fractional)
2-1/2
Type
II
Number of Flutes
2
Shank Diameter (Fractional)
1/4
Neck Diameter (Decimal)
0.0000
Cutting Diameter (Fractional)
3/32
Tapered Reach (Decimal)
0.9720
Neck Angle
5
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0010
End Type
Ball
Helix Angle
35 degrees
LxD Ratio
0.8xD
Material
Solid Carbide
Reach (Decimal)
0.9720
Shank Tolerance
h6
Size System
Fractional
Workpiece Material
Steel, Stainless Steel
Harvey Tool Ball End Mill: 3/32" Dia, .074" LOC, 2-1/2" OAL, .972" Reach, 2 Flute, AlTiN Nano, 38993-C6
$106.20
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
