Harvey Tool Corner Radius End Mill: 3/16" Dia, 5/8" LOC, 2" OAL, .010" Corner Radius, 2 Flute, Amorphous Diamond, 46710-C4

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-46710-C4
$57.70

Harvey Tool corner radius end mill, 2 flutes, center cutting. Solid carbide, Amorphous Diamond coating. Manufacturer part number 46710-C4.

Specifications

Unit of Measure
Inch
Cutting Diameter (Decimal)
0.1875
Length of Cut (Decimal)
0.6250
Shank Diameter (Decimal)
0.1875
Overall Length (Decimal)
2.0000
Coating/Finish
Amorphous Diamond
Length of Cut (Fractional)
5/8
Corner Radius (Decimal)
0.0100
Number of Flutes
2
Shank Diameter (Fractional)
3/16
Cutting Diameter (Fractional)
3/16
Overall Length (Fractional)
2
Center Cutting
Yes
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
End Type
Corner Radius
LxD Ratio
3xD
Material
Solid Carbide
Size System
Fractional
Harvey Tool Corner Radius End Mill: 3/16" Dia, 5/8" LOC, 2" OAL, .010" Corner Radius, 2 Flute, Amorphous Diamond, 46710-C4
$57.70
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
