HT - 58210

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-58210
$35.90
0.1250" (1/8) Shank DIA x 0.0100" Radius x 40° included Carbide Radius Engraver, 1 Flute

Specifications

Unit of Measure
Inch
Length of Cut (Decimal)
0.1520
Shank Diameter (Decimal)
0.1250
Overall Length (Decimal)
1.5000
Coating/Finish
Uncoated
Overall Length (Fractional)
1-1/2
Type
II
Split Length (Decimal)
0.3750
Split Length (Fractional)
3/8
Number of Flutes
1
Included Angle
40 degrees
Shank Diameter (Fractional)
1/8
Radius (Decimal)
0.0100
Angle per Side
20 degrees
End Type
Tip Radius
Material
Solid Carbide
HT - 58210
$35.90
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
