HT - 58515

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-58515
$99.60
0.0150" (1/64) Radius x 0.0600" Head DIA x 0.0930" (3/32) Neck Length Carbide 5° Flare Back Corner Rounding End Mill, 3 Flutes

Specifications

Unit of Measure
Imperial
Overall Length
1.50 Inch
Coating/Finish
UN
Shank Diameter (Fractional)
1/8
Overall Length (Fractional)
1-1/2
Neck Diameter (Decimal)
0.03
Number of Flutes
3
Shank Diameter
0.13 Inch
Neck Length (Decimal)
0.10
Neck Length (Fractional)
3/32
Radius (Decimal)
0.02
Reach Multiple
3x
Head Diameter
0.06 Inch
Pilot Flare
5
Radius (Fractional)
1/64
Radius Center (Decimal)
0.04
Shoulder Flare
5
HT - 58515
$99.60
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
