Harvey Tool Square End Mill: .035" Dia, .105" LOC, 1-1/2" OAL, .315" Reach, 2 Flute, Uncoated, 76235

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-76235
$54.30

Harvey Tool square end mill, 2 flutes, center cutting. Solid carbide, uncoated. Manufacturer part number 76235.

Specifications

Unit of Measure
Inch
Cutting Diameter (Decimal)
0.0350
Length of Cut (Decimal)
0.1050
Shank Diameter (Decimal)
0.1250
Number of Flutes
2
Overall Length (Decimal)
1.5000
Coating/Finish
Uncoated
Overall Length (Fractional)
1-1/2
Neck Diameter (Decimal)
0.0340
Neck Length (Decimal)
0.2100
Shank Diameter (Fractional)
1/8
Size System
Decimal
Cutting Diameter (Metric)
0.90
Center Cutting
Yes
Reach Multiple
9x
Cutting Diameter Tolerance (Decimal)
+0.0005/-0.0005
End Type
Square
LxD Ratio
3xD
Material
Solid Carbide
Reach (Decimal)
0.3150
Harvey Tool Square End Mill: .035" Dia, .105" LOC, 1-1/2" OAL, .315" Reach, 2 Flute, Uncoated, 76235
$54.30
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
