Harvey Tool Corner Radius End Mill: 1/8" Dia, 3/16" LOC, 1-1/2" OAL, .005" Corner Radius, 2 Flute, Uncoated, 767508

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-767508
$52.40

Harvey Tool corner radius end mill for plastics, 2 flutes, center cutting. Solid carbide, uncoated. Manufacturer part number 767508.

Specifications

Unit of Measure
Inch
Cutting Diameter (Decimal)
0.1250
Length of Cut (Decimal)
0.1870
Shank Diameter (Decimal)
0.1250
Overall Length (Decimal)
1.5000
Coating/Finish
Uncoated
Length of Cut (Fractional)
3/16
Overall Length (Fractional)
1-1/2
Corner Radius (Decimal)
0.0050
Number of Flutes
2
Shank Diameter (Fractional)
1/8
Cutting Diameter (Fractional)
1/8
Size System
Fractional
Center Cutting
Yes
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
End Type
Corner Radius
LxD Ratio
1.5xD
Material
Solid Carbide
Workpiece Material
Plastics
Harvey Tool Corner Radius End Mill: 1/8" Dia, 3/16" LOC, 1-1/2" OAL, .005" Corner Radius, 2 Flute, Uncoated, 767508
$52.40
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
