Harvey Tool Ball End Mill: 3/64" Dia, .141" LOC, 2-1/2" OAL, 6 Flute, AlTiN Nano, 843447-C6

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-843447-C6
$72.80

Harvey Tool ball end mill for hardened steel, 6 flutes, variable helix, center cutting. Solid carbide, AlTiN Nano coating. Manufacturer part number 843447-C6.

Specifications

Unit of Measure
Inch
Cutting Diameter (Decimal)
0.0470
Length of Cut (Decimal)
0.1410
Shank Diameter (Decimal)
0.2500
Overall Length (Decimal)
2.5000
Coating/Finish
AlTiN Nano
Overall Length (Fractional)
2-1/2
Number of Flutes
6
Shank Diameter (Fractional)
1/4
Cutting Diameter (Fractional)
3/64
Size System
Fractional
Center Cutting
Yes
Cutting Diameter Tolerance (Decimal)
+0.0005/-0.0005
End Type
Ball
LxD Ratio
3xD
Material
Solid Carbide
Maximum Workpiece Hardness
55 HRC
Secondary Workpiece Material
Stainless Steel, High-Temp Alloy
Shank Tolerance
h6
Variable Helix
Yes
Workpiece Material
Hardened Steel
Harvey Tool Ball End Mill: 3/64" Dia, .141" LOC, 2-1/2" OAL, 6 Flute, AlTiN Nano, 843447-C6
$72.80
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
