Harvey Tool Square End Mill: .020" Dia, .030" LOC, 1-1/2" OAL, .060" Reach, 3 Flute, AlTiN Nano, 940520-C6

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-940520-C6
$85.40

Harvey Tool square end mill for high-temp alloys, 3 flutes, variable helix, center cutting. Solid carbide, AlTiN Nano coating. Manufacturer part number 940520-C6.

Specifications

Unit of Measure
Inch
Cutting Diameter (Decimal)
0.0200
Length of Cut (Decimal)
0.0300
Shank Diameter (Decimal)
0.1250
Number of Flutes
3
Overall Length (Decimal)
1.5000
Coating/Finish
AlTiN Nano
Overall Length (Fractional)
1-1/2
Neck Diameter (Decimal)
0.0192
Shank Diameter (Fractional)
1/8
Size System
Decimal
Cutting Diameter (Metric)
0.50
Center Cutting
Yes
Reach Multiple
3x
Cutting Diameter Tolerance (Decimal)
+0.0005/-0.0005
End Type
Square
LxD Ratio
1.5xD
Material
Solid Carbide
Maximum Workpiece Hardness
45 HRC
Reach (Decimal)
0.0600
Secondary Workpiece Material
Steel, Stainless Steel
Shank Tolerance
h6
Variable Helix
Yes
Workpiece Material
High-Temp Alloy
Harvey Tool Square End Mill: .020" Dia, .030" LOC, 1-1/2" OAL, .060" Reach, 3 Flute, AlTiN Nano, 940520-C6
$85.40
