Harvey Tool Square End Mill: .050" Dia, .075" LOC, 2-1/2" OAL, 13/64" Reach, 3 Flute, Uncoated, 945550

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-945550
$53.30

Harvey Tool square end mill, 3 flutes, center cutting, external coolant. Solid carbide, uncoated. Manufacturer part number 945550.

Specifications

Unit of Measure
Inch
Cutting Diameter (Decimal)
0.0500
Length of Cut (Decimal)
0.0750
Shank Diameter (Decimal)
0.1250
Number of Flutes
3
Overall Length (Decimal)
2.5000
Coating/Finish
Uncoated
Overall Length (Fractional)
2-1/2
Neck Diameter (Decimal)
0.0485
Center Cutting
Yes
Chip Breaker
No
Shank Diameter (Fractional)
1/8
Size System
Decimal
Double Ended
No
Coolant Option
External Coolant
Reach (Decimal)
0.2030
Reach Multiple
4x
Cutting Diameter Tolerance (Decimal)
+0.0005/-0.0005
End Type
Square
LxD Ratio
1.5xD
Material
Solid Carbide
Reach (Fractional)
13/64
Harvey Tool Square End Mill: .050" Dia, .075" LOC, 2-1/2" OAL, 13/64" Reach, 3 Flute, Uncoated, 945550
$53.30
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
