Harvey Tool Cutter: 1/32" Dia, .027" LOC, 1-1/2" OAL, .089" Reach, 2 Flute, AlTiN, 951131-C3

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-951131-C3
$115.40

Harvey Tool cutter, 2 flutes, 45 degree helix, spherical end, center cutting, external coolant. Solid carbide, AlTiN coating. Manufacturer part number 951131-C3.

Specifications

Unit of Measure
Inch
Cutting Diameter (Decimal)
0.0313
Length of Cut (Decimal)
0.0270
Shank Diameter (Decimal)
0.1250
Overall Length (Decimal)
1.5000
Coating/Finish
AlTiN
Overall Length (Fractional)
1-1/2
Neck Diameter (Decimal)
0.0160
Number of Flutes
2
Neck Length (Decimal)
0.0620
Neck Length (Fractional)
1/16
Shank Diameter (Fractional)
1/8
Neck Diameter (Metric)
0.40
Cutting Diameter (Fractional)
1/32
Coolant Option
External Coolant
Radius (Decimal)
0.0156
Radius (Fractional)
1/64
Wrap Angle
270
Center Cutting
Yes
Chip Breaker
No
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0010
Double Ended
No
End Type
Spherical
Helix Angle
45 degrees
Material
Solid Carbide
Reach (Decimal)
0.0890
