Harvey Tool Ball End Mill: 1/4" Dia, 3/4" LOC, 2-1/2" OAL, 3 Flute, Amorphous Diamond, 989816-C4

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-989816-C4
$83.10

Harvey Tool ball end mill for non-ferrous metals, 3 flutes, variable helix, center cutting. Solid carbide, Amorphous Diamond coating. Manufacturer part number 989816-C4.

Specifications

Unit of Measure
Inch
Cutting Diameter (Decimal)
0.2500
Length of Cut (Decimal)
0.7500
Shank Diameter (Decimal)
0.2500
Overall Length (Decimal)
2.5000
Coating/Finish
Amorphous Diamond
Length of Cut (Fractional)
3/4
Overall Length (Fractional)
2-1/2
Number of Flutes
3
Shank Diameter (Fractional)
1/4
Cutting Diameter (Fractional)
1/4
Size System
Fractional
Center Cutting
Yes
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
End Type
Ball
LxD Ratio
3xD
Material
Solid Carbide
Shank Tolerance
h6
Variable Helix
Yes
Workpiece Material
Non-Ferrous
Harvey Tool Ball End Mill: 1/4" Dia, 3/4" LOC, 2-1/2" OAL, 3 Flute, Amorphous Diamond, 989816-C4
$83.10
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
