Kyocera ABS 15-4015 PR1725 Grade PVD Carbide, Indexable Turning Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TLM40004
$63.43
Kyocera ABS15-4015 PR1725 Grade PVD Carbide, 15 Degree, Irregular, Positive Rake Angle, Right-Hand Turning Insert for Light Interruption and Finishing in (P) Carbon/Alloy Steel

Specifications

Series
BTI
Unit of Measure
Imperial
Cutting Direction
Right
Material
Carbide
Coating/Finish
PVD
Primary Workpiece Material
(P) Carbon/Alloy Steel
Corner Radius
0.06 Inch
Style
ABS
Application
Back Turning
Shape
Irregular
Insert Holding Method
Screw or Clamp
Size
15-4015
Old Material Number
8865521
ANSI Part Number
ABS15R4015MPR1725
ISO Part Number
ABS15R4015M
Rake
Positive
Material Group / Grade
PR1725
Cutting Width (Decimal)
0.28
Cutting Width (Metric)
7
Cutting Width Minimum (Decimal)
0.28
Cutting Width Minimum (Metric)
7
Cutting Width Maximum (Decimal)
0.28
Cutting Width Maximum (Metric)
7
Corner Radius (Metric)
1.50
Number of Cutting Edges
2
Insert Length (Decimal)
0.61
Insert Length (Metric)
15.40
Thickness (Metric)
3.97
Cutting Range
Finishing
Usage Classification
Light Interruption
Pack quantity
10
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Small_Part_Tooling_Solutions.pdf
PDF 3
https://s3-us-west-2.amazonaws.com/catsy.739/PR1725_PR1705.pdf
Kyocera ABS 15-4015 PR1725 Grade PVD Carbide, Indexable Turning Insert
$63.43
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
