Kyocera ABS 15R4005M PR1225 Grade PVD Carbide, Indexable Turning Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TKE00103
$63.43
Kyocera ABS 15R4005M PR1225 Grade PVD Carbide, 15 Degree, Irregular, Positive Rake Angle, Right-Hand Turning Insert for Light Interruption and Finishing in (M) Stainless Steel and (P) Carbon/Alloy Steel

Specifications

Series
BTI
Unit of Measure
Imperial
Cutting Direction
Right
Material
Carbide
Coating/Finish
PVD
Primary Workpiece Material
(M) Stainless Steel
Corner Radius
0.002 Inch
Style
ABS
Application
Back Turning
Shape
Irregular
Insert Holding Method
Screw or Clamp
Size
15-4005
Old Material Number
8836006
ANSI Part Number
ABS15R4005MPR1225
ISO Part Number
ABS15R4005M
Rake
Positive
Material Group / Grade
PR1225
Cutting Width (Decimal)
0.28
Cutting Width (Metric)
7
Cutting Width Minimum (Decimal)
0.28
Cutting Width Minimum (Metric)
7
Cutting Width Maximum (Decimal)
0.28
Cutting Width Maximum (Metric)
7
Corner Radius (Metric)
0.05
Number of Cutting Edges
2
Insert Length (Decimal)
0.61
Insert Length (Metric)
15.40
Thickness (Metric)
3.97
Cutting Range
Finishing
Usage Classification
Light Interruption
Pack quantity
10
Kyocera ABS 15R4005M PR1225 Grade PVD Carbide, Indexable Turning Insert
$63.43
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
