Kyocera BDMT 070304ERJT CA6535 Grade CVD Carbide, Indexable Milling Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TMA00286
$24.22
Kyocera BDMT 070304ERJT CA6535 Grade CVD Carbide, Parallelogram, Positive Rake Angle, Right-Hand Milling Insert for Roughing in (M) Martensitic Stainless Steel, (S) Heat-Resistant Alloy

Specifications

Series
MECX
Unit of Measure
Metric
Cutting Direction
Right
Material
Carbide
Coating/Finish
CVD
Primary Workpiece Material
(M) Martensitic Stainless Steel|(S) Heat-Resistant Alloy
Corner Radius
0.40 mm
Corner Radius (Fractional)
1/64
Grade
CA6535
Thickness
2.60 mm
Style
BDMT
Application
Facing, Helical Milling, Shouldering, Slotting
Thickness (Decimal)
0.10
Shape
Parallelogram
Insert Holding Method
Screw
Old Material Number
8842381
ANSI Part Number
BDMT070304ERJTCA6535
ISO Part Number
BDMT070304ER-JT
Rake
Positive
Number of Cutting Edges
2
Insert Size
070304
Chipbreaker
ER-JT
Cutting Range
Roughing
Pack quantity
10
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/MEC-Series_High-Efficiency_Milling.pdf
Kyocera BDMT 070304ERJT CA6535 Grade CVD Carbide, Indexable Milling Insert
$24.22
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
