Kyocera Turning Insert CCGT110902MPCF PR1225: TKE01380
SKU: KYP-TKE01380
Kyocera Turning Insert CCGT110902MPCF PDL010, manufacturer part number TLK01380.
Specifications: IC Size: 0.1380 in (3.50 mm); Insert Thickness: 0.0550 in (1.40 mm); Corner Radius: 0.0040 in (0.10 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8860781; Rake: Positive; Number of Cutting Edges: 2; Cutting Range: Finishing; Usage Classification: Continuous; Insert Size: 110902; Hand Direction: Neutral; Insert Style: CCGT; Insert Shape: 80 Degree Diamond; ANSI Designation: CCGT110902MPCFPDL010; Chip Breaker Type: CF; ISO Designation: CCGT030101MP-CF; Included Angle: 80 degrees; Machining Operations: Boring, External Turning, Facing, Internal Facing, Sub-Spindle; Insert Grade: PDL010; Workpiece Material: Non-Ferrous.
Material: Carbide. Coating/Finish: DLC. Series: ISOI. Unit of measure: Inch.
