Kyocera Turning Insert CNMG644 CA320: TME01072

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TME01072
$40.00

Kyocera Turning Insert CNMG644 CA320, manufacturer part number TME01072.

Specifications: IC Size: 3/4 in (19.05 mm); Insert Thickness: 1/4 in (6.35 mm); Corner Radius: 1/16 in (1.60 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8848516; Rake: Negative; Number of Cutting Edges: 4; Cutting Range: Roughing; Usage Classification: Continuous to Heavy Interruption; Insert Size: 644; Hand Direction: Neutral; Insert Style: CNMG; Insert Shape: 80 Degree Diamond; ANSI Designation: CNMG644CA320; ISO Designation: CNMG190616; Included Angle: 80 degrees; Machining Operations: Boring, External Turning, Facing, Internal Facing; Insert Grade: CA320; Workpiece Material: Cast Iron; Coating Process: CVD.

Material: Carbide. Coating/Finish: TiCN/Al2O3/Ti. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
Carbide
Coating/Finish
TiCN/Al2O3/Ti
Insert Thickness (Fractional)
1/4
Corner Radius (Fractional)
1/16
Included Angle
80
ANSI Designation
CNMG644CA320
Insert Style
CNMG
Insert Thickness (Metric)
6.35
Insert Shape
80 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
644
Old Material Number
8848516
Machining Operations
Boring, External Turning, Facing, Internal Facing
Insert Grade
CA320
Rake
Negative
IC Size (Metric)
19.05
Corner Radius (Metric)
1.60
Number of Cutting Edges
4
Workpiece Material
Cast Iron
Cutting Range
Roughing
Usage Classification
Continuous to Heavy Interruption
IC Size (Fractional)
3/4
Coating Process
CVD
ISO Designation
CNMG190616
Pack quantity
10
