Kyocera Turning Insert CNMM431M KPD010: TBE00401

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TBE00401
$242.58

Kyocera Turning Insert CNMM431M KPD010, manufacturer part number TBE00401.

Specifications: IC Size: 1/2 in (12.70 mm); Insert Thickness: 3/16 in (4.76 mm); Corner Radius: 1/64 in (0.40 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8817264; Rake: Negative; Number of Cutting Edges: 1; Cutting Range: Finishing-Medium; Usage Classification: Continuous; Insert Size: 431; Hand Direction: Neutral; Insert Style: CNMM; Insert Shape: 80 Degree Diamond; ANSI Designation: CNMM431MKPD010; ISO Designation: CNMM120404M; Included Angle: 80 degrees; Machining Operations: Boring, External Turning, Facing, Internal Facing; Insert Grade: KPD010; Workpiece Material: Non-Ferrous, High-Temp Alloy.

Material: PCD. Coating/Finish: Uncoated. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
PCD
Coating/Finish
Uncoated
IC Size (Metric)
12.70
Corner Radius (Fractional)
1/64
Included Angle
80
ANSI Designation
CNMM431MKPD010
Insert Style
CNMM
Insert Thickness (Metric)
4.76
Insert Shape
80 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
431
Old Material Number
8817264
Machining Operations
Boring, External Turning, Facing, Internal Facing
Insert Grade
KPD010
Rake
Negative
Insert Thickness (Fractional)
3/16
Corner Radius (Metric)
0.40
Number of Cutting Edges
1
Workpiece Material
Non-Ferrous, High-Temp Alloy
Cutting Range
Finishing-Medium
Usage Classification
Continuous
IC Size (Fractional)
1/2
ISO Designation
CNMM120404M
