Kyocera Turning Insert CPMH322 KPD010: TBE00148

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TBE00148
$242.58

Kyocera Turning Insert CPMH322 KPD010, manufacturer part number TBE00148.

Specifications: IC Size: 3/8 in (9.525 mm); Insert Thickness: 1/8 in (3.18 mm); Corner Radius: 1/32 in (0.80 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8817394; Rake: Positive; Number of Cutting Edges: 1; Cutting Range: Finishing-Medium; Usage Classification: Continuous; Insert Size: 322; Hand Direction: Neutral; Insert Style: CPMH; Insert Shape: 80 Degree Diamond; ANSI Designation: CPMH322KPD010; ISO Designation: CPMH090308; Included Angle: 80 degrees; Machining Operations: Boring, Internal Facing; Insert Grade: KPD010; Workpiece Material: Non-Ferrous, High-Temp Alloy.

Material: PCD. Coating/Finish: Uncoated. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
PCD
Coating/Finish
Uncoated
Insert Thickness (Fractional)
1/8
Corner Radius (Fractional)
1/32
Included Angle
80
ANSI Designation
CPMH322KPD010
Insert Style
CPMH
Machining Operations
Boring, Internal Facing
Insert Shape
80 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
322
Old Material Number
8817394
Insert Grade
KPD010
Workpiece Material
Non-Ferrous, High-Temp Alloy
Rake
Positive
Insert Thickness (Metric)
3.18
Corner Radius (Metric)
0.80
Number of Cutting Edges
1
Cutting Range
Finishing-Medium
Usage Classification
Continuous
IC Size (Metric)
9.525
ISO Designation
CPMH090308
IC Size (Fractional)
3/8
