Kyocera Turning Insert DCET32505MFRJ TN610: TSS02902

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TSS02902
$29.11

Kyocera Turning Insert DCET32505MFRJ TN610, manufacturer part number TSS02902.

Specifications: IC Size: 3/8 in (9.525 mm); Insert Thickness: 5/32 in (3.97 mm); Corner Radius: 0.0080 in (0.20 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8847919; Rake: Positive; Number of Cutting Edges: 2; Cutting Range: Finishing; Usage Classification: Continuous; Insert Size: 32505; Hand Direction: Right; Insert Style: DCET; Insert Shape: 55 Degree Diamond; ANSI Designation: DCET32505MFRJTN610; Chip Breaker Type: J; ISO Designation: DCET11T302MFR-J; Included Angle: 55 degrees; Machining Operations: Back Boring, Copying, External Turning, Sub-Spindle; Insert Grade: TN610; Workpiece Material: Steel.

Material: Cermet. Coating/Finish: Uncoated. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Right
Material
Cermet
Coating/Finish
Uncoated
Insert Thickness (Fractional)
5/32
Included Angle
55
Corner Radius (Decimal)
0.0080
Insert Style
DCET
Insert Thickness (Metric)
3.97
Insert Shape
55 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
32505
Old Material Number
8847919
Machining Operations
Back Boring, Copying, External Turning, Sub-Spindle
Insert Grade
TN610
Rake
Positive
IC Size (Metric)
9.525
Corner Radius (Metric)
0.20
Number of Cutting Edges
2
Workpiece Material
Steel
ISO Designation
DCET11T302MFR-J
Cutting Range
Finishing
Usage Classification
Continuous
IC Size (Fractional)
3/8
ANSI Designation
DCET32505MFRJTN610
Chip Breaker Type
J
Pack quantity
10
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/Hybrid_Cermet.pdf
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Aerospace_Tooling_Solutions_W.pdf
