Kyocera Turning Insert DCGT2151ELU TN610: TSS03284

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TSS03284
$25.11

Kyocera Turning Insert DCGT2151ELU TN610, manufacturer part number TSS03284.

Specifications: IC Size: 1/4 in (6.35 mm); Insert Thickness: 3/32 in (2.38 mm); Corner Radius: 1/64 in (0.40 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8847932; Rake: Positive; Number of Cutting Edges: 2; Cutting Range: Finishing; Usage Classification: Continuous; Insert Size: 2151; Hand Direction: Left; Insert Style: DCGT; Insert Shape: 55 Degree Diamond; ANSI Designation: DCGT2151ELUTN610; Chip Breaker Type: U; ISO Designation: DCGT070204EL-U; Included Angle: 55 degrees; Machining Operations: Back Boring, Copying, External Turning, Sub-Spindle; Insert Grade: TN610; Workpiece Material: Steel.

Material: Cermet. Coating/Finish: Uncoated. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Left
Material
Cermet
Coating/Finish
Uncoated
Insert Thickness (Fractional)
3/32
Corner Radius (Fractional)
1/64
Included Angle
55
ANSI Designation
DCGT2151ELUTN610
Insert Style
DCGT
Insert Thickness (Metric)
2.38
Insert Shape
55 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
2151
Old Material Number
8847932
Machining Operations
Back Boring, Copying, External Turning, Sub-Spindle
Insert Grade
TN610
Rake
Positive
IC Size (Metric)
6.35
Corner Radius (Metric)
0.40
Number of Cutting Edges
2
Workpiece Material
Steel
ISO Designation
DCGT070204EL-U
Cutting Range
Finishing
Usage Classification
Continuous
IC Size (Fractional)
1/4
Chip Breaker Type
U
Pack quantity
10
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/Hybrid_Cermet.pdf
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Aerospace_Tooling_Solutions_W.pdf
