Kyocera Turning Insert DCMW3252S00435MET KBN020: TFC00090

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TFC00090
$104.64

Kyocera ISOI turning insert for hardened steel, 3/8 in (9.525 mm) IC, 55 degree diamond shape, positive rake, 2 cutting edges, finishing-medium cutting range, screw or clamp insert holding, neutral hand. CBN, MEGACOAT TOUGH (PVD) coating. Manufacturer part number TFC00090.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
CBN
Coating/Finish
MEGACOAT TOUGH
Insert Thickness (Metric)
3.97
Corner Radius (Fractional)
1/32
Included Angle
55
ANSI Designation
DCMW3252S00435METKBN020
Insert Style
DCMW
Machining Operations
Back Boring, Copying, External Turning
Insert Shape
55 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
3252
Insert Grade
KBN020
Workpiece Material
Hardened Steel
Rake
Positive
Insert Thickness (Fractional)
5/32
Corner Radius (Metric)
0.80
Number of Cutting Edges
2
Coating Process
PVD
Cutting Range
Finishing-Medium
Usage Classification
Continuous to Light Interruption
IC Size (Metric)
9.525
ISO Designation
DCMW11T308S01035MET
IC Size (Fractional)
3/8
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/KBN020_Coated_CBN_for_Hardened_Material.pdf
