Kyocera Turning Insert DNGA436S00525ME KBN05M: TBN02207

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TBN02207
$99.73

Kyocera ISOI turning insert for hardened steel, 1/2 in (12.70 mm) IC, 55 degree diamond shape, negative rake, 2 cutting edges, finishing-medium cutting range, screw or clamp insert holding, neutral hand. CBN, MEGACOAT (PVD) coating. Manufacturer part number TBN02207.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
CBN
Coating/Finish
MEGACOAT
Insert Thickness (Fractional)
3/16
Corner Radius (Fractional)
3/32
Included Angle
55
ANSI Designation
DNGA436S00525MEKBN05M
Insert Style
DNGA
Insert Thickness (Metric)
4.76
Insert Shape
55 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
436
Machining Operations
Boring, Copying, External Turning
Insert Grade
KBN05M
Rake
Negative
IC Size (Metric)
12.70
Corner Radius (Metric)
2.40
Number of Cutting Edges
2
Workpiece Material
Hardened Steel
Cutting Range
Finishing-Medium
Usage Classification
Continuous
IC Size (Fractional)
1/2
Coating Process
PVD
ISO Designation
DNGA150424S01225ME
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Aerospace_Tooling_Solutions_W.pdf
PDF 3
https://s3-us-west-2.amazonaws.com/catsy.739/KBN05M_W.pdf
