Kyocera Turning Insert DNGA441T00825 PT600M: TCV02102

Kyocera Turning Insert DNGA441T00825 PT600M, manufacturer part number TCV02102.

Specifications: IC Size: 1/2 in (12.70 mm); Insert Thickness: 1/4 in (6.35 mm); Corner Radius: 1/64 in (0.40 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8827990; Rake: Negative; Number of Cutting Edges: 4; Cutting Range: Finishing-Medium; Usage Classification: Continuous; Insert Size: 441; Hand Direction: Neutral; Insert Style: DNGA; Insert Shape: 55 Degree Diamond; ANSI Designation: DNGA441T00825PT600M; ISO Designation: DNGA150604T02025; Included Angle: 55 degrees; Machining Operations: Boring, Copying, External Turning; Insert Grade: PT600M; Workpiece Material: Hardened Steel, Cast Iron; Coating Process: PVD.

Material: Ceramic - Aluminum Oxide / Titanium Carbide. Coating/Finish: Al2O3/TiC (MEGACOAT). Series: ISOI. Unit of measure: Inch.
