Kyocera Turning Insert DNGG3305RS TN60: TSJ00940

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TSJ00940
$29.60

Kyocera Turning Insert DNGG3305RS TN60, manufacturer part number TSJ00940.

Specifications: IC Size: 3/8 in (9.525 mm); Insert Thickness: 3/16 in (4.76 mm); Corner Radius: 0.0080 in (0.20 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8810133; Rake: Negative; Number of Cutting Edges: 4; Cutting Range: Finishing; Usage Classification: Continuous; Insert Size: 3305; Hand Direction: Right; Insert Style: DNGG; Insert Shape: 55 Degree Diamond; ANSI Designation: DNGG3305RSTN60; Chip Breaker Type: S; ISO Designation: DNGG110402R-S; Included Angle: 55 degrees; Machining Operations: Boring, Copying, External Turning; Insert Grade: TN60; Workpiece Material: Steel.

Material: Cermet. Coating/Finish: Uncoated. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Right
Material
Cermet
Coating/Finish
Uncoated
Insert Thickness (Fractional)
3/16
Included Angle
55
Corner Radius (Decimal)
0.0080
Insert Style
DNGG
Insert Thickness (Metric)
4.76
Insert Shape
55 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
3305
Old Material Number
8810133
Machining Operations
Boring, Copying, External Turning
Insert Grade
TN60
Rake
Negative
IC Size (Metric)
9.525
Corner Radius (Metric)
0.20
Number of Cutting Edges
4
Workpiece Material
Steel
ISO Designation
DNGG110402R-S
Cutting Range
Finishing
Usage Classification
Continuous
IC Size (Fractional)
3/8
ANSI Designation
DNGG3305RSTN60
Chip Breaker Type
S
Pack quantity
10
