Primary Workpiece Material
(N) Non-Ferrous Materials
Corner Radius (Metric)
0.05
Inscribed Circle (Metric)
9.53
Cutting Width (Decimal)
0.02
Application
External Grooving
Thickness (Fractional)
1/8
Insert Holding Method
Screw or Clamp
Old Material Number
8810667
ANSI Part Number
GBA32R050005KW10
ISO Part Number
GBA32R050-005
Number of Cutting Edges
3
Cutting Range
Finishing-Medium
Usage Classification
Light Interruption
Corner Radius (Decimal)
0.002
Cutting Width Minimum (Decimal)
0.02
Cutting Width Minimum (Metric)
0.50
Cutting Width Maximum (Decimal)
0.02
Cutting Width Maximum (Metric)
0.50
Max Depth of Cut (Decimal)
0.04
Max Depth of Cut (Metric)
1
Inscribed Circle (Fractional)
3/8
