Primary Workpiece Material
(N) Non-Ferrous Materials
Corner Radius (Metric)
0.10
Inscribed Circle (Metric)
9.53
Cutting Width (Decimal)
0.06
Application
External Grooving|Internal Grooving
Thickness (Fractional)
1/8
Insert Holding Method
Screw or Clamp
Old Material Number
8810684
ANSI Part Number
GBA32R150010KPD010
ISO Part Number
GBA32R150-010
Number of Cutting Edges
1
Usage Classification
Continuous
Corner Radius (Decimal)
0.004
Cutting Width Minimum (Decimal)
0.06
Cutting Width Minimum (Metric)
1.50
Cutting Width Maximum (Decimal)
0.06
Cutting Width Maximum (Metric)
1.50
Max Depth of Cut (Decimal)
0.08
Max Depth of Cut (Metric)
2
Inscribed Circle (Fractional)
3/8
