Primary Workpiece Material
(H) Hardened Materials
Corner Radius (Metric)
0.20
Inscribed Circle (Metric)
12.70
Cutting Width (Decimal)
0.06
Application
External Grooving|Internal Grooving
Thickness (Fractional)
3/16
Insert Holding Method
Screw or Clamp
Old Material Number
8820772
ANSI Part Number
GBA43L150KBN525
ISO Part Number
GBA43L150-020
Number of Cutting Edges
1
Usage Classification
Continuous
Corner Radius (Decimal)
0.01
Cutting Width Minimum (Decimal)
0.06
Cutting Width Minimum (Metric)
1.50
Cutting Width Maximum (Decimal)
0.06
Cutting Width Maximum (Metric)
1.50
Max Depth of Cut (Decimal)
0.14
Max Depth of Cut (Metric)
3.50
Inscribed Circle (Fractional)
1/2
