Primary Workpiece Material
(P) Steel
Corner Radius (Metric)
0.20
Inscribed Circle (Metric)
12.70
Cutting Width (Decimal)
0.08
Application
External Grooving|Traversing
Thickness (Fractional)
3/16
Insert Holding Method
Screw or Clamp
Old Material Number
8860660
ANSI Part Number
GBA43R200020GMPR1625
ISO Part Number
GBA43R200-020GM
Number of Cutting Edges
3
Cutting Range
Medium-Roughing
Usage Classification
Light Interruption
Corner Radius (Decimal)
0.01
Cutting Width Minimum (Decimal)
0.08
Cutting Width Minimum (Metric)
2
Cutting Width Maximum (Decimal)
0.08
Cutting Width Maximum (Metric)
2
Max Depth of Cut (Decimal)
0.14
Max Depth of Cut (Metric)
3.50
Inscribed Circle (Fractional)
1/2
