Primary Workpiece Material
(P) Steel
Corner Radius (Metric)
0.30
Inscribed Circle (Metric)
12.70
Cutting Width (Decimal)
0.10
Application
External Grooving|Traversing
Thickness (Fractional)
3/16
Insert Holding Method
Screw or Clamp
Old Material Number
8860662
ANSI Part Number
GBA43R250030GMPR1625
ISO Part Number
GBA43R250-030GM
Number of Cutting Edges
3
Cutting Range
Medium-Roughing
Usage Classification
Light Interruption
Corner Radius (Decimal)
0.01
Cutting Width Minimum (Decimal)
0.10
Cutting Width Minimum (Metric)
2.50
Cutting Width Maximum (Decimal)
0.10
Cutting Width Maximum (Metric)
2.50
Max Depth of Cut (Decimal)
0.20
Max Depth of Cut (Metric)
5
Inscribed Circle (Fractional)
1/2
