Primary Workpiece Material
(P) Steel
Corner Radius (Metric)
0.40
Corner Radius (Fractional)
1/64
Inscribed Circle (Metric)
12.70
Cutting Width (Decimal)
0.16
Application
External Grooving
Thickness (Fractional)
3/16
Insert Holding Method
Screw or Clamp
Old Material Number
8846685
ANSI Part Number
GBA43R400040GMTN620
ISO Part Number
GBA43R400-040GM
Number of Cutting Edges
3
Cutting Range
Finishing-Medium
Usage Classification
Continuous
Cutting Width Minimum (Decimal)
0.16
Cutting Width Minimum (Metric)
4
Cutting Width Maximum (Decimal)
0.16
Cutting Width Maximum (Metric)
4
Max Depth of Cut (Decimal)
0.20
Max Depth of Cut (Metric)
5
Inscribed Circle (Fractional)
1/2
