Primary Workpiece Material
(P) Steel
Inscribed Circle (Metric)
9.53
Cutting Width (Decimal)
0.01
Application
External Grooving
Thickness (Fractional)
1/8
Insert Holding Method
Screw
Old Material Number
8867541
ANSI Part Number
GBF32R025000FPR1215
ISO Part Number
GBF32R025-000F
Number of Cutting Edges
3
Cutting Range
Medium-Roughing
Usage Classification
Light Interruption
Cutting Width Minimum (Decimal)
0.01
Cutting Width Minimum (Metric)
0.25
Cutting Width Maximum (Decimal)
0.01
Cutting Width Maximum (Metric)
0.25
Max Depth of Cut (Decimal)
0.02
Max Depth of Cut (Metric)
0.60
Inscribed Circle (Fractional)
3/8
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/GBF_Grooving_for_Small_Parts.pdf
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Small_Part_Tooling_Solutions.pdf
PDF 3
https://s3-us-west-2.amazonaws.com/catsy.739/JCTM-Series.pdf
