Primary Workpiece Material
(P) Steel
Corner Radius (Metric)
0.05
Cutting Width (Decimal)
0.05
Application
Internal Grooving|Small Parts Machining
Insert Holding Method
Screw or Clamp
Insert Length (Decimal)
0.30
Insert Length (Metric)
7.70
Old Material Number
8863882
ANSI Part Number
GC08R125005PR1725
ISO Part Number
GC08R125-005
Number of Cutting Edges
1
Cutting Range
Finishing-Medium
Usage Classification
Light Interruption
Corner Radius (Decimal)
0.002
Cutting Width Minimum (Decimal)
0.05
Cutting Width Minimum (Metric)
1.25
Cutting Width Maximum (Decimal)
0.05
Cutting Width Maximum (Metric)
1.25
Max Depth of Cut (Decimal)
0.06
Max Depth of Cut (Metric)
1.50
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/SIGC_Small_Internal_Grooving.pdf
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Small_Part_Tooling_Solutions.pdf
PDF 3
https://s3-us-west-2.amazonaws.com/catsy.739/PR1725_PR1705.pdf
