ANSI Designation
GDGS4020N040NBKBN570
Corner Radius (Metric)
0.40
Corner Radius (Fractional)
1/64
ISO Designation
GDGS4020N-040NB
Cutting Width (Metric)
4.00
Insert Thickness (Metric)
4.30
Cutting Width (Decimal)
0.1575
Machining Operations
External Grooving
Insert Holding Method
Clamp
Insert Length (Decimal)
0.7874
Insert Length (Metric)
20.00
Number of Cutting Edges
1
Cutting Range
Finishing-Medium
Usage Classification
Continuous
Cutting Width Minimum (Decimal)
0.1575
Cutting Width Minimum (Metric)
4.00
Cutting Width Maximum (Decimal)
0.1575
Cutting Width Maximum (Metric)
4.00
Maximum Depth of Cut (Decimal)
1.0039
Maximum Depth of Cut (Metric)
25.50
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/KGD_KGDF_Grooving_and_Cut-Off.pdf
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Automotive_Tooling_Solutions.pdf
PDF 3
https://s3-us-west-2.amazonaws.com/catsy.739/JCT-Series_Coolant-Through_Holders.pdf
Insert Thickness (Decimal)
0.1690
