Primary Workpiece Material
(P) Steel
Corner Radius (Metric)
0.40
Corner Radius (Fractional)
1/64
Cutting Width (Decimal)
0.16
Application
External Grooving|Traversing
Insert Holding Method
Clamp
Insert Length (Decimal)
0.79
Insert Length (Metric)
20
Old Material Number
8834914
ANSI Part Number
GDM4020N040GMTN90
ISO Part Number
GDM4020N-040GM
Number of Cutting Edges
2
Cutting Range
Finishing-Medium
Usage Classification
Continuous
Cutting Width Minimum (Decimal)
0.16
Cutting Width Minimum (Metric)
4
Cutting Width Maximum (Decimal)
0.16
Cutting Width Maximum (Metric)
4
Max Depth of Cut (Decimal)
1
Max Depth of Cut (Metric)
25.50
