Primary Workpiece Material
(S) Heat-Resistant Alloy
Corner Radius (Metric)
0.40
Corner Radius (Fractional)
1/64
Cutting Width (Decimal)
0.24
Application
External Grooving|Traversing
Insert Holding Method
Clamp
Insert Length (Decimal)
0.79
Insert Length (Metric)
20
Old Material Number
8844587
ANSI Part Number
GDM6020N040GMPR1535
ISO Part Number
GDM6020N-040GM
Number of Cutting Edges
2
Cutting Range
Medium-Roughing
Usage Classification
Light Interruption
Cutting Width Minimum (Decimal)
0.24
Cutting Width Minimum (Metric)
6
Cutting Width Maximum (Decimal)
0.24
Cutting Width Maximum (Metric)
6
Max Depth of Cut (Decimal)
1.18
Max Depth of Cut (Metric)
30
