Kyocera GH 312R15 TC40 Grade Uncoated Cermet, Indexable Grooving Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-8801370
$52.81
Kyocera GH 312R15 TC40 Grade Uncoated Cermet, 0.3125" Groove Width, Right-Hand Grooving Insert for Continuous and Finishing in (P) Steel and (K) Cast Iron

Specifications

Series
LLTH
Unit of Measure
Imperial
Material
Cermet
Coating/Finish
Uncoated
Primary Workpiece Material
(P) Steel
Corner Radius (Metric)
0.38
Grade
TC40
Cutting Width
0.31 Inch
Thickness (Metric)
7.50
Cutting Width (Metric)
7.94
Style
GH
Application
External Grooving
Thickness (Decimal)
0.30
Insert Holding Method
Clamp
Insert Length (Decimal)
0.79
Insert Length (Metric)
20
Size
312
Old Material Number
8801370
ANSI Part Number
GH312R15TC40
ISO Part Number
GH312R15
Rake
Positive
Number of Cutting Edges
2
Hand of Holder
Right
Cutting Range
Finishing
Full Radius
No
Usage Classification
Continuous
Corner Radius (Decimal)
0.02
Cutting Width Minimum (Decimal)
0.31
Cutting Width Minimum (Metric)
7.94
Cutting Width Maximum (Decimal)
0.31
Cutting Width Maximum (Metric)
7.94
Pack quantity
10
