Kyocera GVF L350C KW10 Grade Uncoated Carbide, Indexable Grooving Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TWE02235
$74.79
Kyocera GVF L350C KW10 Grade Uncoated Carbide, 3.50mm Groove Width, Left-Hand Grooving Insert for Light Interruption and Finishing-Medium in (N) Non-Ferrous Metals

Specifications

Series
GFV
Unit of Measure
Metric
Material
Carbide
Coating/Finish
Uncoated
Primary Workpiece Material
(N) Non-Ferrous Materials
Corner Radius (Metric)
0.40
Corner Radius (Fractional)
1/64
Grade
KW10
Cutting Width
3.50 mm
Thickness (Metric)
7
Cutting Width (Decimal)
0.14
Style
GVF
Application
Face Grooving
Chip Breaker Type
C
Thickness (Decimal)
0.28
Insert Holding Method
Clamp
Insert Length (Decimal)
1.06
Insert Length (Metric)
27
Size
350
Old Material Number
8811412
ANSI Part Number
GVFL350CKW10
ISO Part Number
GVFL350-040C
Rake
Positive
Number of Cutting Edges
2
Hand of Holder
Left
Cutting Range
Finishing-Medium
Full Radius
No
Usage Classification
Light Interruption
Cutting Width Minimum (Decimal)
0.14
Cutting Width Minimum (Metric)
3.50
Cutting Width Maximum (Decimal)
0.14
Cutting Width Maximum (Metric)
3.50
Max Depth of Cut (Decimal)
0.27
Max Depth of Cut (Metric)
6.80
Pack quantity
10
