Cutting Diameter (Decimal)
3.1496 - 3.6614
Cutting Diameter (Metric)
80 - 93
Application
Chamfering, Facing
Insert Holding Method
Screw
Old Material Number
8609063
ANSI Part Number
MFPN45080R5T
ISO Part Number
MFPN45080R-5T
Material Group / Grade
GR99
Cutting Diameter Minimum (Decimal)
3.15
Maximum Depth of Cut (Decimal)
0.24(GM/SM/GH), 0.20 (GL), 0.12 (W)
Maximum Depth of Cut (Metric)
6 (GM/SM/GH), 5 (GL), 3 (W)
Cutting Diameter Minimum (Metric)
80
Cutting Maximum (Decimal)
3.66
Connection Bore Diameter (Decimal)
1
Connection Bore Diameter (Metric)
25.40
Contact Surface Diameter Machine Side (Decimal)
2.36
Contact Surface Diameter Machine Side (Metric)
60
Tool Entering Angle
45 degrees
Cutter Pitch
Coarse Pitch
