Cutting Diameter (Decimal)
3.9370 - 4.4488
Cutting Diameter (Metric)
100 - 113
Application
Chamfering, Facing
Insert Holding Method
Screw
Old Material Number
8831586
ANSI Part Number
MFPN45100R6T
ISO Part Number
MFPN45100R-6T
Material Group / Grade
GR99
Cutting Diameter Minimum (Decimal)
3.94
Maximum Depth of Cut (Decimal)
0.24(GM/SM/GH), 0.20 (GL), 0.12 (W)
Maximum Depth of Cut (Metric)
6 (GM/SM/GH), 5 (GL), 3 (W)
Cutting Diameter Minimum (Metric)
100
Cutting Maximum (Decimal)
4.45
Connection Bore Diameter (Decimal)
1.25
Connection Bore Diameter (Metric)
31.75
Contact Surface Diameter Machine Side (Decimal)
2.76
Contact Surface Diameter Machine Side (Metric)
70
Tool Entering Angle
45 degrees
Cutter Pitch
Coarse Pitch
