Kyocera PNEG 1106XNTRT01015W KBN475 Grade CBN, Indexable Milling Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TFB05311
$235.11
Kyocera PNEG 1106XNTRT01015W KBN475 Grade CBN, Pentagon, Negative Rake Angle, Right-Hand Milling Insert for Roughing in (K) Gray Cast Iron, (K) Nodular Cast Iron

Specifications

Series
MFK
Unit of Measure
Metric
Cutting Direction
Right
Material
CBN
Coating/Finish
Uncoated
Primary Workpiece Material
(K) Gray Cast Iron|(K) Nodular Cast Iron
Grade
KBN475
Thickness
6.50 mm
Style
PNEG
Application
Chamfering, Facing
Thickness (Decimal)
0.26
Shape
Pentagon
Insert Holding Method
Screw
Insert Length (Decimal)
0.71
Insert Length (Metric)
18.06
Old Material Number
8860933
ANSI Part Number
PNEG1106XNTRT01015WKBN475
ISO Part Number
PNEG1106XNTR-T01015W
Rake
Negative
Number of Cutting Edges
2
Insert Size
1106
Chipbreaker
XNTR-W
Cutting Range
Roughing
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/MFK_Cast_Iron_Milling_W.pdf
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Automotive_Tooling_Solutions.pdf
PDF 3
https://s3-us-west-2.amazonaws.com/catsy.739/MFK-SF.pdf
