Kyocera Turning Insert RNMG32 PV720: TLD05070

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TLD05070
$21.02

Kyocera Turning Insert RNMG32 PV720, manufacturer part number TLD05070.

Specifications: IC Size: 3/8 in (9.525 mm); Insert Thickness: 1/8 in (3.18 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8862618; Rake: Negative; Number of Cutting Edges: 8; Cutting Range: Medium-Roughing; Usage Classification: Continuous to Light Interruption; Insert Size: 32; Hand Direction: Neutral; Insert Style: RNMG; Insert Shape: Round; ANSI Designation: RNMG32PV720; ISO Designation: RNMG090300; Machining Operations: External Turning, Facing, Undercutting; Insert Grade: PV720; Workpiece Material: Steel; Coating Process: PVD.

Material: Cermet. Coating/Finish: TiCN (MEGACOAT NANO). Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
Cermet
Coating/Finish
TiCN (MEGACOAT NANO)
Insert Thickness (Fractional)
1/8
ANSI Designation
RNMG32PV720
Insert Style
RNMG
Insert Thickness (Metric)
3.18
Insert Shape
Round
Insert Holding Method
Screw or Clamp
Insert Size
32
Old Material Number
8862618
Machining Operations
External Turning, Facing, Undercutting
Insert Grade
PV720
Rake
Negative
IC Size (Metric)
9.525
Number of Cutting Edges
8
Workpiece Material
Steel
Cutting Range
Medium-Roughing
Usage Classification
Continuous to Light Interruption
ISO Designation
RNMG090300
IC Size (Fractional)
3/8
Pack quantity
10
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/Hybrid_Cermet.pdf
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Aerospace_Tooling_Solutions_W.pdf
Coating Process
PVD
