Kyocera TCGT 2202FRU KW10 Grade Uncoated Carbide, Indexable Turning Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TWE00480
$35.95
Kyocera TCGT 2202FRU KW10 Grade Uncoated Carbide, 7 Degree, Triangle, Positive Rake Angle, Right-Hand Turning Insert for Light Interruption and Finishing in (N) Non-Ferrous Metals, (S) Titanium Alloy and (K) Gray Cast Iron

Specifications

Series
ISOI
Unit of Measure
Fractional
Cutting Direction
Right-Hand
Material
Carbide
Coating/Finish
Uncoated
Primary Workpiece Material
(N) Non-Ferrous Materials|(S) Titanium Alloy
Included Angle
60 degrees
Thickness
1/8 Inch
Style
TCGT
Application
External Turning
Shape
60 Degree Triangle
Insert Holding Method
Screw or Clamp
Size
2202
Old Material Number
8814056
ANSI Part Number
TCGT2202FRUKW10
ISO Part Number
TCGT110301FR-U
Rake
Positive
Material Group / Grade
KW10
Corner Radius (Metric)
0.10
Number of Cutting Edges
3
Thickness (Metric)
3.18
Chipbreaker
U
Cutting Range
Finishing
Usage Classification
Light Interruption
Insert Included Angle
60 degrees
Inscribed Circle (Metric)
6.35
Inscribed Circle
1/4 Inch
Pack quantity
10
Kyocera TCGT 2202FRU KW10 Grade Uncoated Carbide, Indexable Turning Insert
$35.95
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
